ELECTRICALS & ELECTRONICS

Automotive electronics are electronic systems used in vehicles, including engine management, battery management, ignition, bulbs and others.
Modern electric cars rely on power electronics for the main propulsion motor control, as well as managing the battery system. Future autonomous
cars will rely on powerful computer systems, an array of sensors, networking, and satellite navigation, all of which will require electronics.
Aopec is carrying a serial of products of relays, wire harness, battery chargers, dual batteries management, ignition wires, bulbs and EV car
charging cables, with complete qualified standard and certificates.

Go To DOWNLOAD CENTER→

Relays

The type most commonly used in the automotive industry is an electro-mechanically operated switch, which employ an electromagnet device to mechanically maneuver a switch to make or break an electrical circuit.
An electro-magnetic relay is constructed of a coil of wire that is wrapped around a soft iron core - known as a solenoid
Aopec offers mini relay, micro relay, HD relay, PCB relay, and solid state relay, from 20A to 100A different current performance, 6V & 12V & 24V & 48V rated voltage, Extended Temperature Range up to 125 °C, Sealed IP67 and Dust Cover Types Available.
Our relays provide critical switching functions in multiple vehicle applications.
BSRs

Battery Sensitive Relay(BSR), also called voltage sensitive relay, is a relay used for automotive, truck and marine applications. A VSR senses the input voltage generated and automatically connects or disconnects the appliance or circuit at pre-set voltages for a variety of applications. It is typically used to prevent over-discharging of a car battery and is very common in a dual-battery system. Aopec offers 12V -24V range with different currents, with exquisite appearance and workmanship, delivering functions of primary battery saver, efficiency charging and extend battery life.

Learn more→
Wire Harnesses

Wire harness, also called automotive socket is suit to the related relay, easy to assembly and connection. Commonly used in automobiles, as well as construction machinery, cable harnesses provide several advantages over loose wires and cables. In spite of increasing automation, hand manufacture continues to be the primary method of cable harness production in general, due to the many different processes involved. Aopec offers varied of wire harness, 0.5mm, 0.75mm, 1.0mm, 1.5mm, 2.0mm,4.0mm etc, according to our customers different requests and needs.
Battery Chargers

A smart charger is defined as a charger that can respond to the condition of a battery, and modify its charging actions accordingly. Chargers for car batteries come in varying ratings, which are rated up to two amperes may be used to maintain charge on parked vehicle batteries or for small batteries on garden tractors or similar equipment. A motorist may keep a charger rated a few amperes to ten or fifteen amperes for maintenance of automobile batteries or to recharge a vehicle battery that has accidentally discharged. Aopec smart chargers give you a revolution in battery charging technology, MCU-controlled, Multiple charging process, Easy to use, Quick-disconnection Accessories. 12V and 6V, from 0.75A, 1.25A, 2A,4A, 8A to 10A and 20A. Suit European CE and USA UL Certificate.

Learn more→
Ignition Wires

An ignition coil, also called a spark coil, is an induction coil in an automobile's ignition system that transforms the battery's low voltage to the thousands of volts needed to create an electric spark in the spark plugs to ignite the fuel A modern passenger automobile may use one ignition coil for each engine cylinder (or pair of cylinders), eliminating fault-prone spark plug cables and a distributor to route the high voltage pulses. It consists of a laminated iron core surrounded by two coils of copper wire. Unlike a power transformer, an ignition coil has an open magnetic circuit — the iron core does not form a closed loop around the windings. The energy that is stored in the magnetic field of the core is the energy that is transferred to the spark plug. Aopec offers both open and closed magnetic types, ranges cover most vehicles of VW, HONDA, OPEL, BMW,AUDI, FIAT, TOYOTA,NISSAN, MAZDA, FORD,HYUNDAI, etc.
Automotive Lamps

Light bulbs for automobiles are made in several standardized series. Bulbs used for headlamps, turn signals and brake lamps may be required to comply with international and national regulations governing the types of lamps used. Other automotive lighting applications such as auxiliary lamps or interior lighting may not be regulated, but common types are used by many automotive manufacturers. Aopec offers large serial of automotive bulbs under Goup1, Group2, Group3, including H1, H3, H4 , H7 to S2 and S3. Halogen, Xeon and LED, etc. Quality warrantied and long life-time.
EV Car Charging Cables

EV cars are growing rapidly recently, the need of their accessories is increasing accordingly. For charging at home or work, no matter you are using a standard electrical outlet or a high-capacity appliance outlet, or a charging station, a qualified charging cable are necessary for your safety and property. The charging time depends on the battery capacity and the charging power The time rate of charge depends on the charging level used, and the charging level depends on the voltage handling of the batteries and charger electronics in the car. The U.S.-based SAE International defines Level 1 (household 120V AC) as the slowest, Level 2 (upgraded household 240 VAC) in the middle and Level 3 (super charging, 480V DC or higher) as the fastest. Aopec offers qualified charging cables of level 1 and level 2, 10A, 16A, 20A, 32A, different meters length available, complying with IEC60245 and IEC60227.
Starter Solenoids

A starter solenoid is an electromagnet which is actuated to engage the starter motor of an internal combustion engine. It is normally attached directly to the starter motor which it controls. ts primary function is as the actuating coil of a contactor (a relay designed for large electric currents) which connects the battery to the starter motor proper. All modern cars also use the starter solenoid to move the starter pinion into engagement with the ring gear of the engine.
